Svodič VPU III R 230V/6KV AC |
| Surge protection for power engineering and power supply, with different requirements. The surge voltage arresters can be used in all applications from the power input in power engineering to the terminals in the power supply. The arrester is installed in the vicinity of the power supply for the equipment requiring protection, in a commercially available installation/electrical distribution housing. Surge voltage arrester (power suply systems), with telecomm. contact, Type III, low voltage network: TN-C, TN-S, TN-C-S, AC,230 V, |
|
|
| U nás zaplatíte s DPH | Kč |
| Cena bez DPH | 1 589 Kč |
| Kód: | 10.861.412 |
| EAN: | 4050118158496 |
| Značka | WEIDMÜLLER |
| Záruční doba | |
|
| Popis | |
Surge protection for power engineering and power supply, with different requirements. The surge voltage arresters can be used in all applications from the power input in power engineering to the terminals in the power supply. The arrester is installed in the vicinity of the power supply for the equipment requiring protection, in a commercially available installation/electrical distribution housing. Surge voltage arrester (power suply systems), with telecomm. contact, Type III, low voltage network: TN-C, TN-S, TN-C-S, AC,230 V,
- Způsob montáže:DIN lišta 35 mm
- S kontaktem pro dálkovou signalizaci:Ano
- Montážní velikost:1 TE
- Typ pólů:1
- Max. trvalé napětí AC:300,00 V
- Jmenovité napětí AC:230,00 V
- Konfigurace sítě:TN-C
- Testovací třída typ 2:Ne
- Signalizace na zařízení:Optický
- Stupeň krytí (IP):IP20
- Odolnost proti zkratu:Ano
- Integrované předjištění:Ne
- Max.průměr neohebného vodiče (:2,50
- Max.průměr ohebného vodiče (je:2,50
|
|
